External Aluminium Base & Stainless Steel Top Drain - Heelguard Pattern

SKU: a1025h
Regular price $244.20
/
Size
Length
Tax included. Shipping calculated at checkout.
  • Anodised Aluminium Base
  • 316 Stainless Steel Top
  • Free In-Store Pickup from our Belmore Warehouse
  • Reliable Shipping Australia-Wide
  • Secure payments
  • In stock, ready to ship
  • Inventory on the way
  • These products are recommended for External use.
  • Looking for an external custom grate, corners or something customised? Let us know here.

  • Proudly Australian Designed and made to Australian Standards

Aluminium Base with Stainless Steel Top

The External Aluminium Grates are CLASS A and suitable for pedestrian traffic.

316 Stainless Steel:

  • This product is made from marine grade 316 stainless steel which is recommended for lifetime durability for internally and externally use.
  • 316 stainless steel is typically used on balconies, walkways, driveways, around pool areas, gardens and many more external applications.

    Heelguard Pattern

    • Grate top is our Heelguard pattern top made from 316 stainless steel
    Available Sizes Heelguard top  Lengths in Meters
    85mm wide x 25mm deep Drawing  1,2
    85mm wide x 40mm deep Drawing  1,2
    115mm wide x 80mm deep Drawing   1,2



    The advantages of our Stainless Steel Heelguard include:

    • 3mm Wedge Wire with 4mm Aperture
    • 5mm (x20mm deep) edge bar all the way around the grate - eliminating any sharp edges
    • Cross bars every 25mm, not touching base of drain the base of the drains allowing plenty of water flow
    • Tapered cross bars reduces the buildup of dirt & grime
    • Heel & Pet Friendly

        Application/Usage Grades:

        • Class A - Light Duty / Suitable for Pedestrian Traffic ONLY
        • Class B - Medium Duty / Suitable for Pedestrian, Car and Light Truck Traffic
        • Class C - Heavy Duty / Pedestrian, Car and Heavy Truck Traffic

        To be safe, we always recommend going for the heavier duty if you are unsure between 2 options.



        Download Brochure

        To find our more information on this product visit either the Brochures or Drawings page.

        Stainless Steel Grates & Drains Maintenance: Download PDF

        Shower Drain Warranty: Download PDF

        So long as this item is in stock, its is usually ready to dispatch next-day. (excludes custom items)

        This item is stocked and shipped from our Belmore Warehouse.

        For more information, visit our Delivery FAQs page.
